Cummins – Meta Power

Cummins 50/60Hz 20-1800kVA

Operations across various applications and industries depend on Cummins generators. In today’s global economy, where uninterrupted power supply is crucial around the clock, Cummins is your trusted source for resilient, adaptable, and seamlessly integrated power solutions, available on-demand or as a continuous service, 24/7.

50Hz

60Hz

50Hz

60Hz

Ningde Meta Power Equipment Co., Ltd. Stands as a prominent and esteemed manufacturer of generators and alternators based in China.

Model	Gensetspower				Diesel engine								Stamford Alternator	OpenType		SilentType
	Prime		Standby		Cummins	Engine prime power	Fuel consumption 100%load		Cylinder× Bore×Stroke	Coo lant	Lubri cation	Fuel tank		Size (LxWxH)	Weight	Size (LxWxH)	Weight
	kW	KVA	kW	kVA	50Hz/1500rpm	kW	g/kW.h	L/h	Qty×mm×mm	L				mm	kg	mm	kg
MP-C25	18	23	20	25	4B3.9-G11	20	236	5.6	4×102×120	27	10.9	44	PI144E	1500×700×1200	715	2100×1000×1300	1075
MP-C30	22	28	24	30	4B3.9-G1/G2	24	229	6.5	4×102×120	27	10.9	52	PI 144F	1600×700×1200	755	2200×1000×1300	1105
MP-C33	24	30	26	33	4B3.9-G12	27	227	7.2	4×102×120	27	10.9	58	PI 144G	1600×700×1200	762	2200×1000×1300	1112
MP-C45	32	40	36	45	4BT3.9-G1/G2	36	214	9.1	4×102×120	27	10.9	73	PI 144K	1700×700×1200	836	2300×1000×1300	1196
MP-C65	48	60	52	65	4BTA3.9-G2	50	213	13	4×102×120	27	10.9	106	UCI224E	1900×700×1200	920	2400×1000×1480	1280
MP-C70	52	65	56	70	4BTA3.9-G2	58	212	14	4×102×120	27	10.9	106	UCI224F	1900×700×1200	955	2400×1000×1480	1315
MP-C88	64	80	70	88	4BTA3.9-G11	70	208	17	4×102×120	27	10.9	112	UCI224G	1950×700×1200	1005	2550×1000×1480	1375
MP-C110F	80	100	88	110	4BTA3.9-G13	87	212	22	4×102×120	27	10.9	165	UCI274C	1950×700×1200	1030	2550×1050×1530	1420
MP-C110S	80	100	88	110	6BT5.9-G1/G2	86	208	21	6×102×120	35	16.4	168	UCI274C	2300×800×1300	1180	2900×1100×1600	1680
MP-C120F	88	110	96	120	4BTAA3.9-G3	96	212	24	4×102×120	27	10.9	192	UCI274D	1950×760×1200	1060	2550×1050×1530	1480
MP-C120S	88	110	96	120	6BTA5.9-G2	96	208	23	6×102×120	35	16.4	188	UCI274D	2300×800×1300	1210	2900×1100×1600	1710
MP-C130	96	120	104	130	6BTA5.9-G2	106	211	26	6×102×120	35	16.4	211	UCI274D	2300×800×1300	1219	2900×1100×1600	1719
MP-C145	108	135	116	145	6BTAA5.9-G2	120	208	29	6×102×120	35	16.4	235	UCI274E	2400×800×1300	1330	3200×1100×1800	1860
MP-C165	120	150	132	165	6BTAA5.9-G12	140	203	33	6×102×120	35	16.4	340	UCI274F	2400×800×1300	1375	3200×1100×1800	1975
MP-C200	144	180	160	200	6CTA8.3-G1/G2	163	212	41	6×114×135	34	27.6	360	UCI274G	2600×900×1500	1680	3300×1100×1900	2280
MP-C220	160	200	176	220	6CTAA8.3-G2	183	205	44	6×114×135	34	27.6	380	UCI274H	2650×900×1500	1745	3500×1120×1900	2435
MP-C250	184	230	200	250	6CTAA8.3-G9	210	204	50	6×114×135	34	27.6	400	UCI274J	2750×900×1500	1795	3500×1120×1930	2475
MP-C275	200	250	220	275	6LTAA8.9-G2/G3	230	195	53	6×114×145	57	27.6	430	UCI274K	2900×1000×1700	1940	3500×1250×2050	2660
MP-C300	220	275	240	300	6LTAA9.5-G3	250	193	57	6×117×148	57	28	550	HCI444D	3200×1100×1800	2273	3900×1400×2200	3393
MP-C360	260	325	288	360	6LTAA9.5-G1	290	199	68	6×117×148	57	28	550	HCI444E	3200×1100×1800	2313	3900×1400×2200	3433
MP-C385	280	350	308	385	NTA855-G2A	310	210	77	6×140×152	61	38.6	560	HCI444E	3300×1100×1800	2910	4000×1400×2200	4010
MP-C410	300	375	330	413	NTAA855-G7	343	210	85	6×140×152	61	38.6	678	HCI444F	3400×1100×1800	2960	4100×1400×2200	4160
MP-C450	328	410	364	455	NTAA855-G7A	370	210	91	6×140×152	61	38.6	731	HCI444F	3400×1100×1800	3010	4100×1400×2200	4210
MP-C500Q	360	450	400	500	QSZ13-G2	400	191	90	6×130×163	77	45.4	690	HCI544C	3500×1400×1900	3370	4300×1800×2250	4820
MP-C500K	360	450	400	500	KTA19-G3	403	203	96	6×159×159	66	38	760	HCI544C	4000×1600×2000	3906	4800×1900×2450	4986
MP-C550Q	400	500	440	550	QSZ13-G3	450	193	102	6×130×163	77	45.4	690	HCI544D	3500×1400×1900	3370	4300×1800×2250	4820
MP-C550K	400	500	440	550	KTA19-G3A	448	203	107	6×159×159	66	50	760	HCI544D	4000×1600×2000	3906	4800×1900×2450	4986
MP-C600	440	550	480	600	KTAA19-G5	470	203	112	6×159×159	66	50	760	HCI544D	4000×1600×2000	3957	4800×1900×2450	5157
MP-C660	480	600	528	660	KTA19-G8	523	206	127	6×159×159	66	50	760	HCI544E	4000×1600×2000	4067	4800×1900×2450	5267
MP-C700	500	625	560	700	KTAA19-G6A	550	206	133	6×159×159	66	50	790	HCI544F	4100×1600×2000	4207	4900×1900×2450	5977
MP-C725	520	650	580	725	QSK19-G3	574	212	143	6×159×159	66	85	790	HCI544F	4100×1600×2000	4247	4900×1900×2450	6017
MP-C800	580	725	640	800	KTA38-GA	640	213	160	12×159×159	199	135	NIA	LVI634B	4500×1700×2300	6200	5800×2250×2500	9540
MP-C825	600	750	660	825	KTA38-G2	664	214	167	12×159×159	199	135	N/A	LVI634B	4500×1700×2300	6488	5800×2250×2500	9828
MP-C880	640	800	704	880	KTA38-G2B	711	213	178	12×159×159	199	135	N/A	LVI634C	4500×1700×2300	6554	5800×2250×2500	9894
MP-C1000	730	913	800	1000	KTA38-G2A	813	200	191	12×159×159	199	135	N/A	LVI634D	4500×1700×2300	6585	5800×2250×2500	9925
MP-C1100	800	1000	880	1100	KTA38-G5	880	202	209	12×159×159	199	135	N/A	LVI634E	4700×1700×2300	6869	5950×2250×2500	10109
MP-C1250	900	1125	1000	1250	KTA38-G9	990	213	248	12×159×159	326	135	N/A	LVI634F	4700×1700×2300	7516	5950×2250×2500	10756
MP-C1400	1000	1250	1100	1375	KTA50-G3	1097	197	254	16×159×159	460	177	N/A	LVI634G	5200×2100×2400	9208	I*40HQ	17208
MP-C1500	1100	1375	1212	1515	KTA50-G8	1200	205	289	16×159×159	460	205	N/A	PI734B	5200×2100×2400	9960	I*40HQ	17960
MP-C1650	1180	1475	1300	1625	KTA50-GS8	1287	204	309	16×159×159	460	205	N/A	PI734C	5200×2100×2400	10061	I*40HQ	18061
MP-C1900	1350	1688	1500	1875	KTA50-G15X	1491	195	342	16×159×159	460	205	N/A	PI734D	5200×2100×2400	10735	I*40HQ	18735
MP-C2000	1500	1875	1600	2000	KTA50-G16A	1650	204	396	16×159×159	460	234	N/A	PI734E	5200×2100×2400	10973	I*40HQ	18973
MP-C2000	1500	1875	1650	2062.5	QSK60-G3	1615	195	370.5	16×159×190	60.2	14:1	TC	PI734E	6200×2250×2500	13176	I*40HQ	19560
MP-C2200	1600	2000	1760	2200	QSK60-G4	1730	195	396.88	16×159×190	60.2	14:1	TC	PI734F	6200×2250×2500	13660	I*40HQ	20320

Model	Gensetspower				Diesel engine								Stamford Alternator	OpenType		SilentType
	Prime		Standby		Cummins	Engine prime power	Fuel consumption 100%load		Cylinder× Bore×Stroke	Coo lant	Lubri cation	Fuel tank		Size (LxWxH)	Weight	Size (LxWxH)	Weight
	kW	KVA	kW	kVA	60Hz/1800rpm	kW	g/kW.h	L/h	Qty×mm×mm	L				mm	kg	mm	kg
MP-C28	20	25	22	28	4B3.9-G11	23	236	6.4	4×102×120	27	10.9	51	PI144D	1500×700×1200	715	2100×1000×1300	1075
MP-C33	24	30	26	33	4B3.9-G2	30	237	8.4	4×102×120	27	10.9	67	PI144E	1600×700×1200	755	2200×1000×1300	1105
MP-C40	28	35	32	40	4B3.9-G12	33	237	9.2	4×102×120	27	10.9	74	PI144F	1600×700×1200	762	2200×1000×1300	1112
MP-C50	36	45	40	50	4BT3.9-G2	40	220	10.4	4×102×120	27	10.9	83	PI144J	1700×700×1200	836	2300×1000×1300	1196
MP-C70	52	65	56	70	4BTA3.9-G2	60	213	15	4×102×120	27	10.9	106	UCI224E	1900x700x1200	920	2400×1000×1480	1280
MP-C100	72	90	80	100	4BTA3.9-G11	80	208	20	4×102×120	27	10.9	112	UCI224F	1950x700x1200	1005	2550×1000×1480	1375
MP-C110	80	100	88	110	4BTA3.9-G13	97	208	24	4×102×120	27	10.9	165	UCI224G	1950x700x1200	1030	2550×1050×1530	1420
MP-C125	92	115	100	125	4BTAA3.9-G3	106	212	26	4×102×120	27	10.9	212	UCI274C	1950x760x1200	1060	2550×1050×1530	1480
MP-C120	88	110	96	120	6BT5.9-G2	100	228	27	6×102×120	35	16.4	215	UCI274C	2300×800×1300	1180	2900×1100×1600	1680
MP-C140	100	125	112	140	6BT5.9-G2	115	228	31	6×102×120	35	16.4	247	UCI274C	2300×800×1300	1210	2900×1100×1600	1710
MP-C150	110	138	120	150	6BTA5.9-G2	120	211	30	6×102×120	35	16.4	238	UCI274D	2300×800×1300	1219	2900×1100×1600	1719
MP-C165	120	150	132	165	6BTAA5.9-G2	132	208	32	6×102×120	35	16.4	258	UCI274E	2400×800×1300	1330	3200×1100×1800	1860
MP-C190	136	170	152	190	6BTAA5.9-G12	150	203	36	6×102×120	35	16.4	340	UCI274E	2400×800×1300	1375	3200×1100×1800	1975
MP-C210	152	190	168	210	6CTA8.3-G2	170	212	42	6×114×135	45	27.6	360	UCI274F	2600×900×1500	1680	3300×1100×1900	2280
MP-C230	168	210	184	230	6CTAA8.3-G2	190	205	46	6×114×135	45	27.6	380	UCI274G	2650×900×1500	1745	3500×1120×1900	2435
MP-C275	200	250	220	275	6CTAA8.3-G9	240	204	58	6×114×135	45	27.6	400	UCI274H	2750×900×1500	1795	3500×1120×1930	2475
MP-C300	220	275	240	300	6LTAA8.9-G3	255	195	59	6×114×145	57	27.6	430	UCI274J	2900×1000×1700	1940	3500×1250×2050	2660
MP-C350	256	320	280	350	6LTAA9.5-G1	280	199	66	6×117×148	57	28	550	HCI444C	3200×1100×1800	2313	3900×1400×2200	3433
MP-C385	280	350	308	385	NTA855-G1B	313	210	77	6×140×152	61	38.6	560	HCI444D	3300×1100×1800	2910	4000×1400×2200	4010
MP-C440	320	400	352	440	NTAA855-G3	358	206	87	6×140×152	61	38.6	694	HCI444ES	3400×1100×1800	2960	4100×1400×2200	4160
MP-C500Q	360	450	400	500	QSZ13-G2	400	193	91	6×130×163	77	45.4	690	HCI444E	3500x1400x1900	3370	4300×1800×2250	4820
MP-C500K	360	450	400	500	KTA19-G2	392	210	97	6×159×159	66	38	760	HCI444E	4000x1600x2000	3906	4800×1900×2450	4986
MP-C550Q	400	500	440	550	QSZ13-G3	450	197	104	6×130×163	77	45.4	690	HCI444F	3500x1400x1900	3370	4300×1800×2250	4820
MP-C550K	400	500	440	550	KTA19-G3	463	203	111	6×159×159	66	38	760	HCI444F	4000x1600x2000	3906	4800×1900×2450	4986
MP-C625Q	450	563	500	625	QSZ13-G11	512	201	121	6×130×163	77	45.4	760	HCI544C	3500x1400x1900	3370	4300×1800×2250	4820
MP-C625K	450	563	500	625	KTA19-G3A	507	203	121	6×159×159	66	38	760	HCI544C	4000x1600x2000	3906	4800×1900×2450	4986
MP-C660	480	600	528	660	KTAA19-G5	533	203	127	6×159×159	66	50	760	HCI544C	4000x1600x2000	3957	4800×1900×2450	5157
MP-C750	544	680	600	750	KTAA19-G6A	600	206	145	6×159×159	66	50	790	HCI544E	4100x1600x2000	4207	4900×1900×2450	5977
MP-C850	620	775	680	850	KTA38-G	679	193	154	12×159×159	199	135	N/A	HCI544F	4500×1700×2300	6488	5800×2250×2500	9828
MP-C960	700	875	770	963	KTA38-G1	768	215	194	12×159×159	199	135	N/A	LVI634C	4500×1700×2300	6200	5800×2250×2500	9540
MP-C1000	728	910	800	1000	KTA38-G2	809	214	204	12×159×159	199	135	N/A	LVI634C	4500×1700×2300	6488	5800×2250×2500	9828
MP-C1040	750	938	830	1038	KTA38-G2B	830	219	214	12×159×159	199	135	N/A	LVI634D	4500×1700×2300	6554	5800×2250×2500	9894
MP-C1130	800	1000	900	1125	KTA38-G2A	915	209	225	12×159×159	199	135	N/A	LVI634D	4500×1700×2300	6585	5800×2250×2500	9925
MP-C1250	900	1125	1000	1250	KTA38-G4	1007	207	245	12×159×159	199	135	N/A	LVI634E	4700×1700×2300	6869	5950×2250×2500	10109
MP-C1380	1000	1250	1100	1375	KTA38-G9	1110	199	260	12×159×159	326	135	N/A	LVI634F	4700×1700×2300	7516	5950×2250×2500	10756
MP-C1580	1100	1375	1260	1575	KTA50-G3	1220	203	291	16×159×159	460	177	N/A	PI734A	5200×2100×2400	9208	I*40HQ	17208
MP-C1790	1220	1525	1430	1788	KTA50-G12	1347	204	323	16×159×159	460	205	N/A	PI734B	5200×2100×2400	9960	I*40HQ	17960
MP-C1880	1260	1575	1500	1875	KTA50-G9	1383	204	332	16×159×159	460	205	N/A	PI734B	5200×2100×2400	10061	I*40HQ	18061
