Deutz – Meta Power

Deutz 50Hz 25-825kVA

Deutz embodies a rich tradition of pioneering spirit, unwavering passion, and a culture of innovation. As a fully independent provider of diesel, gas, and electric drive-trains spanning the power range up to 620 kW, we are actively shaping the technologies required for the challenges of tomorrow. We stand as trailblazers in the realm of high-quality, Eco-conscious, and efficient propulsion systems tailored for off-highway applications.

In a world marked by escalating complexity, driven by stringent emission regulations, we stand by our customers with deep-rooted expertise in system integration and exhaust gas after-treatment. With our top-tier services, we ensure maximum availability, globally and around the clock.

50Hz

Model	Gensetspower				Diesel engine								Alternator	OpenType		SilentType
	Prime		Standby		DEUTZ	Engine prime power	Fuel consumption 100%load		Cylinder× Bore×Stroke	Coolant	Lubric ation	Fuel tank	Meta Power	Size (LxWxH)	Weight	Size (LxWxH)	Weight
	kW	KVA	kW	kVA	50Hz/1500rpm	kW	g/kW.h	L/h	Qty×mm×mm	L			50Hz	mm	kg	mm	kg
MP-D23	16	20	18	23	BFM3G1	20	228	5.4	4×98×105	20	7.5	43	184ES	1350×700×1100	471	1950×900×1200	641
MP-D28	20	25	22	28	BFM3G2	29	226	6.4	4×98×105	20	7.5	62	184FS	1600×750×1200	520	2100×1000×1220	690
MP-D33	24	30	26	33	BFM3G2	29	226	7.7	4×98×105	20	7.5	62	184G	1600×750×1200	525	2200×1000×1220	695
MP-D44	32	40	35	44	BFM3T	40	218	10	4×98×105	20	7.5	80	224C	1700×750×1200	576	2300×1000×1220	776
MP-D55	40	50	44	55	BFM3C	45	212	11	4×98×105	20	7.5	88	224D	1800×750×1200	630	2300×1000×1220	820
MP-D66	48	60	53	66	BF4M2012	54	216	14	4×101×126	22	8.5	110	224E	1900×750×1200	926	2500×1000×1220	1126
MP-D83	60	75	66	83	BF4M2012CG1	71	217	18	4×101×126	22	8.5	152	224F	2000×750×1200	968	2600×1000×1220	1238
MP-D100	72	90	80	100	BF4M2012CG2	85	213	21	4×101×126	22	8.5	184	274C	2100×750×1200	1085	2900×1100×1500	1365
MP-D110	80	100	88	110	BF4M1013ECG1	97	212	24	4×108×130	27	11	194	274C	2100×900×1600	1150	2900×1100×1500	1570
MP-D125	90	113	100	125	BF4M1013ECG2	105	211	26	4×108×130	27	11	209	274D	2200×900×1600	1240	3000×1100×1500	1660
MP-D145	104	130	116	145	BF4M1013FC	117	210	29	4×108×130	27	11	231	274E	2250×900×1600	1250	3100×1100×1500	1690
MP-D175	128	160	140	175	BF6M1013ECG1	146	209	36	6×108×130	33	20	287	274F	2550×900×1750	1530	3100×1100×1500	1800
MP-D200	144	180	160	200	BF6M1013ECG2	160	208	39	6×108×130	33	20	316	274G	2700x1050x1700	1630	3300×1300×1700	1840
MP-D210	150	188	168	210	BF6M1013FCG2	166	208	41	6×108×130	37	31	328	274G	2700×1050×1700	1650	3300×1300×1700	1860
MP-D220	160	200	176	220	BF6M1013FCG3	183	212	46	6×108×130	37	31	360	274H	2700×1050×1700	1680	3400×1300×1700	2000
MP-D275	200	250	220	275	TCD8.0	225	195	52	6×110×136	37	31	416	274K	2700×1150×1800	2130	3600×1300×1800	3680
MP-D330	240	300	264	330	TCD8.7	265	195	61	6×117×135	37	31	488	434D	2700×1150×1800	2350	3900×1600×2050	3900
MP-D350	260	325	280	350	TCD12.1 G1	290	195	67	6×130×150	57	30	536	434ES	2800×1150×1900	2350	3900×1600×2050	3900
MP-D415	300	375	332	415	TCD12.1 G2	330	196	76	6×130×150	57	30	605	434FS	2900×1150×1900	2380	3900×1600×2050	4100
MP-D500	360	450	400	500	TCD13.0 G1	395	188	87	8×131×160	57	30	728	534C	3100×1150×1900	3105	4500×1600×2250	4600
MP-D550	400	500	440	550	TCD13.0 G1	440	191	99	8×131×160	57	30	816	534D	3100×1150×1900	3265	4500×1600×2250	4650
MP-D250	180	225	200	250	BF6M1015-GA	208	195	48	6×132×145	37	38	384	274J	2500×1020×1870	2011	3500×1300×1800	3700
MP-D275	200	250	220	275	BF6M1015C-G1A	228	195	52	6×132×145	37	38	421	274K	2700×1150×2150	2090	3600×1300×1800	3800
MP-D330	220	275	264	330	BF6M1015C-G2A	256	195	59	6×132×145	37	38	472	434DS	2800×1150×2150	2260	3900×1600×2050	3850
MP-D350	250	313	280	350	BF6M1015C-G3A	282	195	65	6×132×145	37	38	520	434D	2800×1150×2150	2350	3900×1600×2050	3900
MP-D385	280	350	308	385	BF6M1015C-G4	310	195	71	6×132×145	37	38	572	434E	2800×1150×2150	2350	3900×1600×2050	3950
MP-D415	300	375	332	415	BF6M1015CP-G	328	195	75	6×132×145	37	38	605	434FS	2800×1150×2150	2380	3900×1600×2050	4100
MP-D480	350	438	384	480	BF8M1015C-G1A	388	196	89	8×132×145	56	48	716	534C	3050×1400×2100	3105	4500×1600×2250	4600
MP-D500	360	450	400	500	BF8M1015C-G2	403	196	93	8×132×145	56	48	743	534C	3050×1400×2100	3105	4500×1600×2250	4600
MP-D525	380	475	420	525	BF8M1015CP-G1A	413	196	95	8×132×145	56	48	762	534C	3050×1400×2100	3265	4500×1600×2250	4650
MP-D550	400	500	440	550	BF8M1015CP-G2	448	196	103	8×132×145	56	48	826	534D	3050×1400×2100	3265	4500×1600×2250	4650
MP-D565	410	513	452	565	BF8M1015CP-G3	458	196	106	8×132×145	56	48	845	534D	3050×1400×2100	3420	4500×1600×2250	4750
MP-D600	430	538	480	600	BF8M1015CP-G4	480	196	111	8×132×145	56	48	885	534D	3150×1550×2100	3450	4600×1800×2250	4750
MP-D625	450	563	500	625	BF8M1015CP-G5	509	196	117	8×132×145	56	48	939	534D	3150×1550×2100	3450	4600×1800×2250	4850
MP-D750	550	688	600	750	HC12V132ZL-G1A	600	197	139	12×132×145	70	54	1107	534G	4000×1800×2500	3500	5400×2200×2650	6000
MP-D825	600	750	660	825	HC12V132ZL-G2A	666	197	154	12×132×145	70	54	1229	634B	4000×1800×2500	3700	5400×2200×2650	6200
Beinei Air-cooled
D17AC	12	15	13	17	F2L912D	14	238	3.9	2×100×120	N/A	8	31	164D	1300×700×1100	465	2000×1100×1250	645
D28AC	20	25	22	28	F3L912D	24	232	6.6	3×100×120	N/A	10	53	184FS	1400×700×1100	503	2200×1100×1250	713
D34AC	25	31	28	34	F4L912D	32	228	8.6	4×100×120	N/A	11	69	184G	1500×700×1100	568	2290×1100×1250	783
D41AC	30	38	33	41	F4L913D	34	228	9.1	4×102×125	N/A	11	73	184H	1500×700×1100	628	2400×1100×1250	878
D50AC	36	45	40	50	F4L912TD	41	220	11	4×100×120	N/A	11	85	224C	1600×730×1200	640	2500×1100×1250	890
D55AC	40	50	44	55	F6L912D	48	228	13	6×100×120	N/A	14	103	224D	1800×750×1200	756	2800×1100×1600	1016
D70AC	50	63	56	70	F6L912TD	61	228	16	6×100×120	N/A	14	132	224E	2000×800×1300	860	2900×1100×1600	1130
D110AC	80	100	88	110	BF6L913D	88	228	24	6×102×125	N/A	14	184	274C	2100×1000×1400	1015	3000×1100×1600	1295
D140AC	100	125	112	140	BF6L913CD	114	224	30	6×102×125	N/A	14	240	274D	2250×1050×1400	1110	3100×1100×1600	1400
